Industrial Jib
Industrial Jib - Lift truck jibs enable the operator to reach over obstacles to be able to place their very heavy loads on decks, roofs or elevated platforms. They are often utilized to reach through second or third story doorways and even windows so as to lift and transfer loads to areas still under construction. Fork truck jibs are really utilized to be able to deliver trucks and flatbed trailers, to laminate wood and suspend trusses. Jibs are even often used for reaching over scaffolding intended for masonry work.
Each forklift jib attachment is equipped with two revolving hooks. One of the hooks can be manually fitted on the base of the boom at whichever position whereas the second hook stays connected at the end of the jib. This enables the person operating it to pick up objects that have two hook points. Dependent on the dimensions of the model, every hook is rated at either four thousand or six thousand lbs. It's possible to utilize either a hook or even two in order to pick up a load. The operator should make sure that the whole weight of the jib and the load will not go over the rated capability of the jib as shown on the load chart for that retracted or extended position.
Attachments jibs could be used on extendable-reach forklifts, rough terrain straight-mast forklifts or even on industrial forklifts. The forklift jib cranes could be fitted onto the forklift by means of inserting both of the forks into the fork pockets. The rear of the jib crane then seats towards the back of the fork and a safety chain wraps the forklift carriage to hold it into place.
Load Capacity for the Jib Boom Forklift Attachment
The maximum load capacity intended for forklift jibs in both the extended or retracted positions range beginning from 1935 pounds up to 6000 lbs. It's a good suggestion to ask a material handling specialist concerning the restrictions for your specific use. The load capacity ratings are really meant for the jib itself and not the lift truck or the utmost load which could be transferred securely making use of a certain lift truck. It is important to remember that at any time when any attachments like for instance a lift truck jib are added to the forklift, the new center of gravity made by the attachment would reduce the overall lift capacity of the forklift. There are directions obtainable that offer information on the way to accurately determine these load limits.
Safe Usage of your Fork Lift Attachment & Fork Trucks
Before the use of whatever forklift jib, make sure that the shackles and hooks are properly secured to the forklift. Make sure and also double check that the pins are tight. It is very important that the load calculations have been correctly made and double checked. Remember to take into consideration the fact that rated capacities occasionally decrease every time the boom is in a raised position, each time the boom is extended with telehandlers or even each time the mast is tilted frontward.
Vital pointers whenever utilizing an adjustable jib is not to ever pull a load with this sort of attachment. These types of accessories are actually just meant for vertical raising. Additionally, refrain from letting the load move back and forth. Use extreme caution each time a load is carried in order to avoid tipping over the truck.
Click to Download the pdf
