Fork Extension for Forklift
Forklift Fork Extensions - Forklift extensions are a terrific choice when there is a need to reach further than your existing blades would allow. In certain circumstances when you have a load which exceeds more than can be securely raised on your forklift, an extension could help you carry out your task safely.
Increasing Forklift Efficiency
Lift truck extensions offer the added support and capacity required when picking up containers, long pallets or really heavy loads. Furthermore, the extensions add more length to the forks which helps the individual operating it to reach increased distances. Utilizing lift truck extensions saves a business the need to purchase separate equipment so as to do the task. This could save possibly thousands of dollars while adding more productivity and efficiency options utilizing the machinery you already have.
A lot of extensions just slip over the standard lift truck blades. Extensions could be purchased in order to fit forks which have widths of 4", 5" and 6". It is essential to measure your extensions in order to obtain a correct fit. Knowing that extensions have an inside width which is half an inch wider than the size stated is paramount to making sure the right fit. Whenever purchasing your extension size, be sure it is equal to your blade's width. For example, if you have blades which are six inches wide, you will utilize an extension that is 6 inches wide.
OSHA Standards
OSHA standards for safety have a guideline length for blade extensions. According to this particular guideline, fork extensions cannot be longer than 50 percent of the original fork length. Abiding by these rules would help to sustain a safe operation. A yellow powder coat finish is added to the metal lift truck extensions so as to avoid corrosion. The two most common measurements for lift truck extensions in the business are sixty inches and seventy two inches, even though, other lengths are offered.
Securing Mechanism
There are two separate securing systems existing. The first alternative secures the extensions onto the lift truck with one pull pin. The second and safer option is the safety loop which is welded on and provides a more secure attachment of the extension. The lift truck extensions are available in both non-tapered or tapered for the majority of container and pallet loads. Triangular extensions are utilized when moving cylinder loads.
Cylinder Loads
Loads that have drums, coils or pipes are considered to be cylinder loads. Extensions for cylinder loads are likewise constructed of steel. They are designed to fit forks up to 2" thick and which are 4" to 5" in width. Secured in place using a locking bar, they slide on and off easily. Triangular extensions range in length from fifty four to sixty inches.
Safety Measures
Safety measures must be utilized when utilizing whichever industrial device or machine and forklift extensions are no different. Checking your forklift extensions prior to utilizing them is a really good habit to get into. Right after placing an extension onto the lift truck, the securing device must be inspected. Physical injury or destruction to the load could take place if the extensions were to become loose and fall off. Following OSHA regulations will also help in order to ensure the safety of the person operating it and people working close by.
