Side Tilt Carriage - Rated by the blade carriage lifting capacity, there are actually four sizes of hook type tine carriages. The hook type blade carriages have been standardized.
The carriage bar spacing utilized for Class 1 is approximately 13 inches and the Class 1 carriage is rated to hold cargo as much as 2000lbs. The Class 2 carriage is rated to carry cargo up to 5,500lbs with carriage bar spacing of sixteen inches. Class III carriages are rated for loads as much as 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing utilized for this capacity is 25 inches.
The carriages for pin type tines may be different depending on the manufacturer. Pin mounted tines can vary by the amount of offset between the fork eye and the tine. Carriage capacity will be determined by the carriage pin size and by the blade size.
