Forklift Drive Axle

Forklift Drive Axle - A lift truck drive axle is actually a piece of equipment that is elastically fastened to a vehicle frame with a lift mast. The lift mast is fixed to the drive axle and is capable of being inclined around the axial centerline of the drive axle. This is done by no less than one tilting cylinder. Frontward bearing components along with rear bearing elements of a torque bearing system are responsible for fastening the drive axle to the vehicle framework. The drive axle could be pivoted around a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing elements. The lift mast is also capable of being inclined relative to the drive axle. The tilting cylinder is connected to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented practically parallel to a plane extending from the axial centerline and to the swiveling axis.

Lift truck units such as H40, H45 and H35 that are made in Aschaffenburg, Germany by Linde AG, have the lift mast tilt ably mounted on the vehicle framework. The drive axle is elastically attached to the lift truck framework utilizing a multitude of bearing devices. The drive axle has tubular axle body together with extension arms attached to it and extend backwards. This type of drive axle is elastically attached to the vehicle frame by rear bearing parts on the extension arms together with frontward bearing tools located on the axle body. There are two back and two front bearing devices. Each one is separated in the transverse direction of the lift truck from the other bearing device in its respective pair.

The braking and drive torques of the drive axle are sustained through the rear bearing elements on the frame utilizing the extension arms. The lift mast and the load create the forces which are transmitted into the road or floor by the framework of the vehicle through the drive axle's front bearing components. It is vital to ensure the parts of the drive axle are configured in a firm enough way to maintain immovability of the forklift truck. The bearing components could lessen small road surface irregularities or bumps all through travel to a limited extent and give a bit smoother function.
